10 Port FTTH Fiber Access Terminal (FAT) / NAP Box IP68 Pre-Connectorized Distribution Enclosure

Name: 10-Port FTTH FAT NAP Box IP68 Pre-Connectorized Enclosure
SKU: MST017-10PFAT

P/N: MST017-10PFAT

Categories:

MST Boxes

Product Highlights:

10-port FTTH FAT/NAP distribution box
Pre-connectorized plug-and-play design
IP68 waterproof and dustproof enclosure
No fusion splicing required
Suitable for aerial, pole, wall, and underground use

Description

The 10-Port Fiber Access Terminal (FAT) / Network Access Point (NAP) Box (Model SP-JW002-10R) is a compact FTTH/FTTx fiber distribution enclosure designed to serve as a termination and access point between feeder and drop cables. It enables efficient fiber splicing, splitting, and distribution while maintaining secure management of outdoor fiber infrastructure. With a pre-connectorized plug-and-play design, it eliminates the need for field fusion splicing, significantly reducing installation time, labor costs, and deployment complexity. Built from high-strength PP+GF material and rated IP68, the enclosure provides excellent protection against water, dust, and harsh environmental conditions, ensuring stable long-term performance in last-mile fiber access networks across a wide range of installation environments.

Specification

Port Capacity	10 Ports
Configuration	1 Input / 9 Outputs
Material	PP + GF
Protection Rating	IP68
Dimensions	269 × 237 × 94 mm
Weight	1.39 kg
Cable Entry/Exit	1月9日
Installation Methods	Wall / Pole / Aerial / Underground

Features

10-port FTTH fiber access terminal design
Pre-connectorized plug-and-play structure
IP68-rated waterproof and dustproof protection
No field fusion splicing required
High-strength PP+GF durable enclosure
Integrated fiber splicing, splitting, and cable management
Flexible installation: aerial, wall, pole, or underground
Optimized internal layout for stable fiber routing

Application

FTTH last-mile access networks
FTTx distribution and termination points
Outdoor telecom fiber deployment
Residential and commercial broadband networks
Aerial, pole-mounted, and underground fiber systems

FAQ

Q1: Does this FAT/NAP box require fusion splicing in the field?
A1: No, it is pre-connectorized and designed for plug-and-play installation without field fusion splicing.

Q2: What environments is this product suitable for?
A2: It is suitable for outdoor, underground, pole-mounted, and wall-mounted FTTH deployments.

Q3: What level of protection does it provide?
A3: It is rated IP68, ensuring full protection against dust and water ingress.

Q4: What material is used for the enclosure?
A4: It is made of high-strength PP+GF (polypropylene with glass fiber reinforcement) for durability.

Q5: Can it support both splitting and termination functions?
A5: Yes, it integrates fiber splicing, splitting, and termination within a single enclosure.
