IP67 ODVA Waterproof Fiber Optic Terminal Box with 8 Fast-Connect Ports for FTTA
Categories:
Product Highlights:
- 8-port ODVA waterproof FTTA terminal box
- IP67-rated outdoor protection
- Fast-connect plug-and-play design
- No fusion splicing required
- Ideal for base station fiber deployment
Table of Contents
Description
The IP67 ODVA Waterproof Fiber Optic Terminal Box is a compact and rugged FTTA distribution enclosure designed to provide fast and reliable fiber connectivity in outdoor wireless infrastructure deployments. It serves as a secure interface between feeder and drop cables, enabling efficient termination and distribution through fast-connect hardened ports without the need for complex field splicing. Supporting up to 8 ODVA or Mini SC waterproof connectors, it simplifies fiber installation, optional splitting, and structured cable management within a single sealed housing. With IP67-rated protection and robust construction, the enclosure ensures stable performance in harsh outdoor environments exposed to dust, rain, and UV radiation, making it ideal for telecom base station and wireless access applications.
Specification
| Connector Compatibility | ODVA, Mini SC, ODVA-style hardened connectors |
|---|---|
| Port Capacity | Up to 8 Ports |
| Material | High-Quality ABS |
| Protection Rating | IP67 |
| Dimensions | 250 × 80 × 70 mm |
| Operating Temperature | -40°C to +65°C |
| Storage Temperature | -40°C to +70°C |
| Durability | > 500 mating cycles |
Features
- 8-port ODVA / Mini SC fast-connect waterproof interface
- IP67-rated dustproof and waterproof protection
- Designed for FTTA outdoor base station deployment
- Mechanically sealed rugged enclosure structure
- Plug-and-play installation without fusion splicing
- Supports fiber termination and optional splitting
- Optimized internal fiber routing and management
- OEM customization available for project requirements
Application
- FTTA (Fiber to the Antenna) base station networks
- Wireless telecom infrastructure deployment
- Outdoor fiber distribution for 4G/5G systems
- Remote radio unit (RRU) connectivity
- Harsh environment outdoor fiber access points
FAQ
Q1: What is the main application of this ODVA terminal box?
A1: It is mainly used in FTTA base station and wireless telecom infrastructure for outdoor fiber connectivity.
Q2: What connector types are supported?
A2: It supports ODVA and Mini SC hardened waterproof fast-connect connectors.
Q3: Is fusion splicing required for installation?
A3: No, it is designed for plug-and-play installation using pre-terminated waterproof connectors.
Q4: Can it withstand harsh outdoor conditions?
A4: Yes, the IP67 rating ensures protection against dust, rain, and UV exposure.
Q5: Is this product customizable?
A5: Yes, OEM customization is available based on project requirements such as port layout and configuration.
FTTA MST Boxes Comparison Table
| SKU | Fiber Capacity | External Ports | Connector Interface | Internal Configuration | Splitter | IP Rating | Mounting |
| MST01-24MAMLCSL | 24 | 12 | OptiTap MPO | Yes/Optional | 2MPO – 24 LC Harness | IP68/IP67 | Pole/Wall Mount |
| MST01-4MAMSASL-P30FT | 4 | 4 | OptiTap SC/APC | Yes/Optional | 1 to 4 | IP67 | Pole/Wall Mount |
| MST011-816PSCA | 8 | 4 or 8 | Customed | Optional | Optional | Optioanl | Wall Mount |
| MST013-16PMSC | 16 | 16 | Mini SC | Splice Tray | Optional | IP68 | Pole/Wall Mount/Aerial |
| MST015-12P19 | 12 to 24 | 12 | Customed | Optional | 1:09 | IP68 | Wall Mount |
| MST016-1016PSA | 10 to 16 | 8 | SC/APC | Splice Tray | Optional | IP68 | Pole/Wall Mount/Aerial |
| MST017-10PFAT | 10 | 10 | Customed | Optional | Optional | IP68 | Pole/Wall Mount |
| MST02-12MAMLCSL | 12 | 6 | OptiTap MPO | Pre-terminated | Optional | IP67 | Wall Mount |
| MST020-12A | 24 | 24 | Hardened Adapter | Pre-terminated | 2 to 24 | IP68/IP67 | Wall Mount |
| MST022-12P | 12 | 12 | Mini SC Harneded | Pre-terminated | Optional | IP68/IP67 | Wall Mount |
| MST024-24C | 8 to 16 | 8 | SuperTap | Pre-terminated | Optional | IP68/IP67 | Wall Mount |
| MST023-16PSC | 16 | 16 | SC FastConnector | Pre-terminated | Optional | IP68/IP67 | Wall Mount |
| MST04-M16ST | 6 | 6 | SuperTap | Pre-terminated | PLC | IP67 | na |
| MST06-68 | 4 to 12 | 4/5/8/12 | SuperTap | Pre-terminated | PLC | IP68 | Wall Mount |
Quality Qulifications and Compliance
To get the detailed certification, please go to the Compliance.
Please Note: Our products comply with all internationally recognized and industry-standard specifications. For customized or special requirement products, we carry out testing and standards in accordance with the conformity criteria specified in the contract.
