5-Port Two-Layer MST Fiber Access Terminal Box IP68 Multiport Service Terminal with SuperTap/FastConnect Adapters
Categories:
Product Highlights:
- 5-port MST with two-layer design
- Plug-and-play with pre-terminated fibers
- SuperTap/FastConnect compatible
- IP68 waterproof and dustproof
- Flexible installation for outdoor networks
Table of Contents
Description
The 5-Port Two-Layer MST Fiber Access Terminal is a compact and high-performance multiport service terminal designed for efficient FTTx-ODN deployments. Featuring factory pre-terminated inlet and outlet fibers, it enables true plug-and-play installation without the need for field splicing or reopening closures, significantly improving deployment speed and reliability. Equipped with hardened adapter ports compatible with SuperTap and FastConnect systems, it ensures seamless connectivity and strong interoperability across network components. The two-layer internal structure enhances fiber routing and management while maintaining a rugged IP68-rated enclosure for superior protection in harsh outdoor environments. Suitable for multiple installation scenarios, this MST terminal helps reduce operational complexity and lowers total cost of ownership for network operators.
5-Port Two-Layer MST Fiber Access Terminal Box Size / Structure
Specification
| Port Count | 5 Ports (2/4/6/8/12 optional) |
|---|---|
| Structure | Two-layer fiber management design |
| Protection Rating | IP68 Waterproof & Dustproof |
| Connector Type | SuperTap / FastConnect Compatible Hardened Adapters |
| Fiber Termination | Factory pre-terminated (no field splicing required) |
| Input Cable Types | SST, ROC, or 5.0mm round cable |
| Stub Length Range | 10 ft – 1500 ft (customizable) |
| Installation Methods | Wall, pole, aerial, pedestal, handhole |
| Cable Type | Toneable or Dielectric Cables |
| Installation | Pole, pedestal, handhole or strand mounting options |
| Stub Length | 20ft -1000ft(Custom lengths are available) |
| Compatible Adapter Type | SC/APC Hardened adapter, Compatible with Tap and H connector |
Features
- 5-port multiport service terminal design
- Two-layer structure for optimized fiber management
- IP68-rated enclosure for harsh outdoor environments
- Compatible with SuperTap and FastConnect adapters
- Factory pre-terminated fibers for plug-and-play deployment
- Eliminates field splicing and reduces installation time
- Supports wall, pole, aerial, and handhole installation
- Customizable configurations available
Applications
- FTTH and FTTx-ODN access networks
- FTTA and wireless infrastructure deployment
- Outdoor fiber distribution points
- Aerial and pole-mounted installations
- Underground handholes and vaults
- Rapid deployment network projects
FAQ
Q1: What is the advantage of the two-layer design?
A1: The two-layer structure improves fiber routing, separation, and protection, making installation and maintenance more efficient.
Q2: Are the ports compatible with different connector systems?
A2: Yes, the terminal supports SuperTap and FastConnect adapters, ensuring flexibility and interoperability.
Q3: Does this product require field splicing?
A3: No, it features factory pre-terminated fibers, enabling plug-and-play installation without splicing.
Q4: Is the enclosure suitable for extreme outdoor conditions?
A4: Yes, the IP68-rated housing provides excellent protection against water, dust, and harsh environments.
Q5: Can the configuration be customized?
A5: Yes, port types, cable lengths, and internal configurations can be tailored to specific project needs.
Quality Qulifications and Compliance
To get the detailed certification, please go to the Compliance.
Please Note: Our products comply with all internationally recognized and industry-standard specifications. For customized or special requirement products, we carry out testing and standards in accordance with the conformity criteria specified in the contract.
