FC/UPC Quick Assembly Connector Hot Melt Type, Single Mode 9/125, Black
Categories:
Product Highlights:
-
FC/UPC Quick Assembly Hot Melt Connector for single-mode 9/125 fiber, black housing, supporting 0.9 mm, 2.0 mm, and 3.0 mm cables.
-
Pre-installed fiber stub and hot-melt design allow field termination in about 100 seconds without epoxy or polishing.
-
Ideal for FTTH, LAN, access networks, and patch panels requiring low insertion loss and reliable UPC performance.
-
FiberMania provides OEM/ODM solutions including custom boot sizes, colors, branding, and pre-terminated patch cord assemblies.
Table of Contents
Description
The FC/UPC Quick Assembly Hot Melt Connector from FiberMania offers a fast, reliable, and field-ready solution for single-mode fiber termination. Designed for rapid deployment, this connector eliminates the need for epoxy, polishing, or special tools, allowing installation directly on-site in minutes. Pre-installed fiber stubs with optical alignment gel ensure precise alignment, low insertion loss, and stable return loss performance, making it ideal for FTTH, LAN, and access network applications.
This universal connector supports 0.9 mm tight-buffer fiber, 2.0 mm, and 3.0 mm cables, including FTTH drop cables. Its hot-melt design allows up to three re-termination attempts, providing flexibility for adjustments during field installation. The black housing identifies the FC/UPC type, while the integrated strain-relief boot protects the fiber and ensures durable, repeatable connections.
Specification
| Connector Type | FC/UPC Hot Melt |
|---|---|
| Fiber Mode | Single Mode 9/125 |
| Ferrule Diameter | 1.25 mm |
| Housing Material | Plastic |
| Boot Diameter | — |
| Ferrule Material | Ceramic |
| Insertion Loss | ≤ 0.3 dB |
| Return Loss | ≥ 50 dB |
| Durability | ≥ 1000 mating cycles |
| Alignment Sleeve | Ceramic |
| Operating Temperature | -40°C to +85°C |
| Compliance | RoHS compliant |
| Color | Black |
Features
-
FC/UPC simplex connector with low insertion loss (≤0.30 dB)
-
Hot-melt design: no epoxy, no polishing, no special tools required
-
Pre-installed fiber stub with optical gel for accurate alignment
-
Quick field termination in about 100 seconds
-
Supports 0.9 mm, 2.0 mm, and 3.0 mm fiber jackets and FTTH drop cables
-
Allows up to three re-termination attempts
-
Can be installed directly on-site without splicing
-
RoHS-compliant materials
-
Mechanical durability: 500 mating cycles
Application
-
Fiber patch panels and distribution frames
-
FTTH outlet connections
-
LAN and access network installations
-
Industrial and military optical networks
-
Field installations requiring fast and reliable fiber termination
FAQ
Q: How fast can this connector be installed in the field?
A: Approximately 100 seconds per fiber termination, without cutting or splicing.
Q: Which cable types are compatible?
A: 0.9 mm, 2.0 mm, and 3.0 mm fiber jackets, including FTTH drop cables.
Q: What are the typical insertion and return losses?
A: Insertion loss ≤0.30 dB, return loss >50 dB (UPC) or >65 dB (APC).
Q: Can the connector be reused?
A: Yes, it supports up to three re-termination attempts.
Q: Is this connector RoHS compliant?
A: Yes, all materials comply with RoHS environmental standards.
