10Gbps SFP+ Transceiver, LR, 2KM, Multimode 1310nm
Categories:
Product Highlights:
-
10Gbps SFP+ LR transceiver with 1310nm FP transmitter and PIN receiver, supporting multimode fiber links up to 2km.
-
Duplex LC interface, hot-pluggable SFP+ form factor with digital diagnostics for monitoring.
-
Ideal for 10G Ethernet and legacy multimode fiber deployments.
-
FiberMania provides OEM/ODM customization and private-label manufacturing
Table of Contents
Description
The 10Gbps SFP+ LR Transceiver is a high-performance optical module designed for short- to medium-reach 10G networks over legacy multimode fiber (MMF). Operating at 1310nm, it supports the 10GBASE-LRM Ethernet standard and enables reliable 10Gbps data transmission up to 2 kilometers on OM1 multimode fiber.
This module integrates a 1310nm Fabry-Perot (FP) laser transmitter and a linear multimode PIN photodiode receiver in a compact LC package. Its linear-interface design works in conjunction with host board Electronic Dispersion Compensation (EDC) to correct modal dispersion, ensuring stable transmission even over legacy FDDI multimode fiber installations.
The SFP+ module is lead-free, RoHS compliant, and features low power consumption, a metal enclosure for EMI protection, and a duplex LC connector. Its small form factor allows high port density, making it suitable for data centers and high-performance networking environments.
Specification
| Data Rate | 10Gbps |
|---|---|
| Wavelength | 1310nm |
| Fiber Type | Multimode (MMF) |
| Transmission Distance | 2KM |
| Connector Type | LC Duplex |
| Compliance | SFP+ MSA, Class I laser, RoHS |
| Power Supply | 3.3V |
| Temperature Range | 0°C to +70°C |
| Features | Hot-pluggable, DDM |
| Application | 10G Ethernet, Fibre Channel |
| Customization | OEM/ODM: wavelengths, distances, labeling, private-label |
| Compatibility | SFP+/XFP MSA-compliant devices |
Features
-
Supports 9.95 to 10.3Gbps data rates
-
Transmission distance up to 2km on OM1 multimode fiber
-
1310nm FP laser transmitter with PIN receiver
-
Duplex LC optical connector
-
Hot-pluggable SFP+ form factor
-
Digital status monitoring interface (DDM)
-
RoHS compliant and lead-free
-
Metal enclosure for EMI protection
-
Single +3.3V power supply
-
Power dissipation < 1W
-
Operating case temperature: 0°C to +70°C
-
Compliant with FC-PI-4 800-Mx-SN-I, SFF-8431, SFF-8432, and SFF-8472
Application
-
10GBASE-LRM 10 Gigabit Ethernet
-
Legacy FDDI multimode fiber links
-
Data center interconnects
-
High-density network switches and routers
FAQ
Q: What is the maximum distance for this SFP+ LR module on multimode fiber?
A: Up to 2 kilometers on OM1 fiber.
Q: Is this module hot-pluggable?
A: Yes, it can be inserted or removed without shutting down network equipment.
Q: Does it support legacy FDDI multimode fiber?
A: Yes, with host board EDC compensation, it supports legacy FDDI multimode links.
Q: What type of optical connector does it use?
A: Duplex LC connector.
Q: Can FiberMania provide OEM/ODM or private-label solutions?
A: Yes, full customization, labeling, and private-label manufacturing services are available.
Quality Qulifications and Compliance
To get the detailed certification, please go to the Compliance.
Please Note: Our products comply with all internationally recognized and industry-standard specifications. For customized or special requirement products, we carry out testing and standards in accordance with the conformity criteria specified in the contract.
