MPO to SC Duplex Cassette 12 Core 6 Port High Density Fiber Module
Categories:
Product Highlights:
- MPO to 6 SC duplex cassette supporting 12 fiber cores for efficient fiber breakout
- High-density modular design for organized and scalable fiber management
- Low loss and plug-and-play structure ensure fast deployment and stable performance
- Compatible Patch Panels: 1U 144-Core: FPP-12M3Q-1U-144F, 2U 288-Core: FPP-24M3Q-2U-288F, 4U 576-Core: FPP-48M3Q-4U-576F
Table of Contents
Description
The MPO to 6 SC Duplex Fiber Optic Cassette is engineered to provide efficient fiber breakout and structured connectivity within high-density fiber networks. By converting a single MPO interface into six SC duplex ports, this module supports a total of 12 fiber cores, enabling seamless transition from backbone trunk cabling to standard SC-based distribution systems. It is an ideal solution for environments that require organized fiber management and reliable performance.
Designed with a compact and modular structure, the cassette allows for fast deployment and easy integration into fiber patch panels and enclosures. Its plug-and-play functionality reduces installation time and minimizes the risk of errors, making it suitable for both new installations and system upgrades. The internal fiber routing is optimized to maintain proper bend radius, ensuring stable signal transmission and long-term reliability.
Manufactured with precision components and strict quality standards, the cassette delivers low insertion loss and consistent optical performance. Its modular design also supports flexible network scaling, allowing users to expand or reconfigure fiber infrastructure as needed without major disruptions.
Specification
| Product Type | MPO to SC Fiber Cassette |
|---|---|
| Fiber Count | 12 Cores |
| Interface | MPO to SC Duplex |
| SC Ports | 6 Duplex |
| Fiber Type | SM / MM (OS2, OM3, OM4, OM5 optional) |
| Connector Type | MPO/MTP to SC |
| Polishing Type | UPC / APC (customizable) |
| Polarity | Type A / B / C (customizable) |
| Insertion Loss | ≤0.35 dB (typical) |
| Return Loss | ≥20 dB (MM) / ≥50 dB (SM) |
| Housing Material | ABS / Metal (optional) |
| Operating Temperature | -20°C to +70°C |
| Application | High-density patch panels |
Features
- Converts 1 MPO interface to 6 SC duplex ports (12 fibers)
- High-density design for efficient fiber breakout
- Plug-and-play module for quick and easy installation
- Low insertion loss for reliable optical performance
- Optimized internal routing to protect fiber bend radius
- Compact cassette for space-saving integration
- Compatible with standard fiber patch panels and enclosures
- Supports single mode and multimode applications
Applications
- Data centers and cloud infrastructure
- Enterprise network cabling systems
- MPO backbone to SC distribution conversion
- Fiber distribution frames (FDF)
- Telecommunications networks
- Structured cabling and high-density environments
FAQs
Q1: What is the function of this MPO to SC cassette?
It converts a single MPO connection into multiple SC duplex ports, enabling easy distribution of fiber signals to end devices.
Q2: Is this cassette compatible with standard patch panels?
Yes, it is designed to fit standard modular fiber patch panels and enclosures.
Q3: Can this module support both single mode and multimode fibers?
Yes, it can be configured for either fiber type depending on application requirements.
Q4: Does it support plug-and-play installation?
Yes, the cassette is pre-terminated and designed for quick plug-and-play deployment.
Q5: Do you offer customization services for this product?
Yes, FiberMania provides OEM/ODM and private label services, including custom configurations, branding, and packaging.
Quality Qulifications and Compliance
To get the detailed certification, please go to the Compliance.
Please Note: Our products comply with all internationally recognized and industry-standard specifications. For customized or special requirement products, we carry out testing and standards in accordance with the conformity criteria specified in the contract.
