LC Simplex Connector, Single Mode, Blue Housing, 2.0mm Boot
Categories:
Product Highlights:
-
High-performance LC simplex connector for single mode 9/125 fiber
-
Low insertion loss and ultra-low back reflection for optimal signal quality
-
Compatible with 2.0mm jacketed fiber and 900µm buffered fiber
-
FiberMania provides flexible OEM/ODM customization for boot colors, ferrule types, and labeling, ensuring your connectors meet precise project requirements
Table of Contents
Description
The LC Simplex Connector is a high-quality single mode connector designed for 9/125µm fiber, providing reliable and precise optical connections for a wide range of networking applications. Its epoxy-type construction ensures low insertion loss and ultra-low back reflection, making it ideal for LAN, WAN, and broadband networks where signal integrity is critical.
This connector features a one-piece pre-domed ceramic ferrule, which allows for easy assembly while maintaining excellent alignment and consistent performance. The corrosion-resistant body enhances durability, ensuring reliable operation in demanding environments.
With a 2.0mm boot, this connector supports jacketed fiber and is compatible with various installation scenarios, offering flexibility for high-density cabling systems and professional networking projects.
Specification
| Connector Type | LC Simplex |
|---|---|
| Fiber Mode | Single Mode |
| Ferrule Diameter | 1.25 mm |
| Housing Material | Plastic |
| Boot Diameter | 2.0 mm |
| Ferrule Material | Ceramic |
| Insertion Loss | ≤ 0.3 dB |
| Return Loss | ≥ 50 dB |
| Durability | ≥ 1000 mating cycles |
| Alignment Sleeve | Ceramic |
| Operating Temperature | -40°C to +85°C |
| Compliance | RoHS compliant |
| Color | Blue |
Features
-
Low insertion loss and ultra-low back reflection
-
Corrosion-resistant housing for long-term reliability
-
One-piece pre-domed ceramic ferrule for easy assembly
-
Compatible with 2.0mm jacketed fiber or 900µm buffered fiber
-
Meets Telecordia GR-326-CORE specifications
-
RoHS compliant
Applications
-
LAN and WAN networks
-
Telecommunication systems
-
Broadband and CATV
-
FTTx projects
-
Optical fiber test equipment
FAQ
Q1: Is this connector compatible with multimode fiber?
A1: No, this LC connector is specifically designed for single mode 9/125 fiber.
Q2: What boot sizes are supported?
A2: This connector supports 2.0mm jacketed fiber and can also accommodate 900µm buffered fiber.
Q3: How durable is the connector?
A3: Rated for over 1,000 mating cycles, ensuring long-term reliability.
Q4: Can FiberMania customize the boot color or labeling?
A4: Yes, we provide full OEM/ODM services to meet your project-specific requirements.
Q5: Does the connector meet environmental standards?
A5: Yes, it is RoHS compliant and uses UL certified materials.
Quality Qulifications and Compliance
To get the detailed certification, please go to the Compliance.
Please Note: Our products comply with all internationally recognized and industry-standard specifications. For customized or special requirement products, we carry out testing and standards in accordance with the conformity criteria specified in the contract.
