ST Male-FC Female OM2 Multimode Simplex Fiber Optic Adapter

Name: ST Male-FC Female OM2 Simplex Fiber Adapter | FiberMania
SKU: STMFCF2S

P/N: STMFCF2S

Categories:

Hybrid Adapters

Product Highlights:

ST male to FC female OM2 multimode hybrid simplex adapter with ceramic sleeve and nickel brass housing for low-loss, stable multimode connectivity.
Ideal for data centers, LAN/WAN networks, FTTX, and broadband systems requiring ST-to-FC interconnection.
Provides mechanical reliability and long-term performance for repeated mating cycles.
FiberMania offers full OEM/ODM customization, private labeling

Description

The ST Male–FC Female OM2 Multimode Simplex Fiber Optic Adapter is a hybrid adapter designed to connect ST-terminated multimode fibers to FC-based optical equipment. Its precision ceramic alignment sleeve ensures low insertion loss and stable optical performance, making it ideal for data centers, telecom networks, and structured cabling systems.

Built with a durable nickel brass housing, this hybrid adapter provides excellent mechanical stability and corrosion resistance for long-term use. The ST male connector offers bayonet-style secure engagement, while the FC female interface provides threaded coupling for reliable mating with FC connectors. Fully tested and inspected prior to shipment, the adapter is engineered for consistent multimode signal transmission in OM2 50/125 μm fiber systems.

Specification

Adapter Type	ST Male-FC Female
Fiber Mode	Multimode
Configuration	Simplex
Insertion Loss	≤ 0.2 dB
Compliance	IEC, Telcordia GR-326, JIS standards; RoHS-compliant materials
Operating Temperature	-40°C to +85°C
Storage Temperature	-40°C to +120°C
Durability	≥ 1000 mating cycles

Features

Meets IEC, Telcordia GR-326, and JIS performance standards
High-precision ceramic alignment sleeve for stable multimode connection
Nickel brass housing for durability and corrosion resistance
RoHS-compliant materials
100% inspected before shipment
Hybrid ST male to FC female simplex configuration

Application

Data center interconnects
Telecommunication network infrastructure
Enterprise and premise installations
LAN and WAN optical systems
FTTX access networks
Broadband and multimode network cross-connections

Q&A

Q1: Can this adapter be used with OM1 or OM3 fibers?
A1: Yes, it is compatible with OM1/OM3 multimode fibers if core size and connector type are supported.

Q2: Why choose nickel brass housing?
A2: Nickel brass provides superior mechanical strength, corrosion resistance, and durability for long-term use.

Q3: Is the ceramic sleeve necessary for multimode fibers?
A3: Yes, it ensures accurate alignment and low insertion loss, especially for repeated mating cycles.

Q4: Can this adapter be customized for duplex applications?
A4: Yes, FiberMania can manufacture duplex or multi-adapter hybrid configurations on request.

Q5: How many mating cycles can this adapter handle?
A5: It is rated for at least 1000 mating cycles with consistent optical performance.

Quality Qulifications and Compliance

To get the detailed certification, please go to the Compliance.

Please Note: Our products comply with all internationally recognized and industry-standard specifications. For customized or special requirement products, we carry out testing and standards in accordance with the conformity criteria specified in the contract.
