100G QSFP28 SWDM4 Optical Transceiver, 100m, Multi-Mode Fiber, LC
Categories:
Product Highlights:
-
100G QSFP28 SWDM4 optical transceiver for high-speed multi-mode fiber links
-
Supports 100Gbps aggregate data rate over 100m OM4/OM5 fiber
-
Hot-pluggable QSFP28 form factor with duplex LC connectors
-
FiberMania provides OEM, ODM, and private-label services for flexible customization and scalable production
Table of Contents
Description
The 100G QSFP28 SWDM4 LC optical transceiver is a high-performance, cost-effective solution designed for 100G Ethernet and data center interconnects. Utilizing SWDM4 (Short-Wavelength Division Multiplexing) technology, it enables 100Gbps aggregate transmission over duplex OM4/OM5 multimode fiber up to 100 meters, reducing fiber cabling requirements and infrastructure costs.
Ideal for cloud networks, enterprise storage systems, and high-performance computing (HPC) environments, this transceiver delivers plug-and-play simplicity with carrier-grade durability. Its QSFP28 form factor supports high-density port deployments, while four parallel 25Gbps lanes using VCSEL-based transmitters ensure reliable high-speed performance with low power consumption (<3.5W).
The module is equipped with duplex LC connectors for standard multi-mode fiber networks and complies with QSFP28 MSA, SWDM MSA, and IEEE802.3bm standards. With its CAUI-4 electrical interface and operating temperature range of 0°C to 70°C, this transceiver offers a dependable, scalable solution for next-generation data center networks.
Specification
| Form Factor | QSFP28 |
|---|---|
| Data Rate | 100Gbps (4x25Gbps) |
| Wavelength | SWDM4 850nm (four short wavelengths) |
| Transmission Distance | Up to 100m on OM4/OM5 MMF |
| Fiber Type | Multi-Mode Fiber (MMF) |
| Connector | Duplex LC |
| Electrical Interface | CAUI-4 |
| Transmitter | VCSEL-based |
| Power Dissipation | <3.5W |
| Diagnostic Function | Digital Diagnostic Monitoring (DDM) |
| Operating Temperature | 0°C ~ 70°C |
| Compliance | QSFP28 MSA, SWDM MSA, IEEE802.3bm, RoHS |
Features
-
Supports 100G QSFP28 and SWDM4 MSA standards
-
Four 25Gbps VCSEL-based transmitters (103.1Gbps aggregate)
-
Transmission distance up to 100m over OM4/OM5 multimode fiber
-
Hot-pluggable QSFP28 form factor
-
Duplex LC connectors for multi-mode fiber
-
CAUI-4 electrical interface
-
Power dissipation <3.5W
-
Operating temperature: 0°C~70°C
-
RoHS compliant
Applications
-
100G Ethernet networks
-
Data center interconnects (DCI)
-
Cloud computing infrastructure
-
Enterprise storage networks
-
High-performance computing (HPC) clusters
FAQ
What is the maximum reach of this transceiver?
Up to 100 meters on OM4 or OM5 multimode fiber.
Which wavelengths are used in SWDM4 technology?
SWDM4 uses four short wavelengths over duplex fiber, allowing 100Gbps transmission on standard multi-mode fiber.
Does it support real-time monitoring?
Yes, it supports standard QSFP28 digital diagnostics for voltage, temperature, bias, and optical power.
Which form factor does it use?
Hot-pluggable QSFP28, ideal for high-density deployment.
Can FiberMania provide OEM or private-label versions?
Yes, FiberMania offers OEM, ODM, and private-label services, including custom labeling, wavelength tuning, and performance optimization.
Quality Qulifications and Compliance
To get the detailed certification, please go to the Compliance.
Please Note: Our products comply with all internationally recognized and industry-standard specifications. For customized or special requirement products, we carry out testing and standards in accordance with the conformity criteria specified in the contract.
