100G QSFP28 Active Optical Cable (AOC), 70m, OM3
Categories:
Product Highlights:
- 100G QSFP28 active optical cable
- 70m maximum reach over OM3 fiber
- Four-channel 850nm VCSEL/PIN architecture
- Integrated CDR for signal integrity
- Supports 100GbE and InfiniBand FDR/EDR
- Plug-and-play solution for high-density data centers
Table of Contents
Description
The 100G QSFP28 Active Optical Cable (AOC) is a four-channel parallel optical interconnect designed for 100GbE and InfiniBand FDR/EDR applications. Equipped with QSFP28 connectors on both ends, it integrates four 850nm VCSEL transmit channels and four PIN receiver channels to provide 100Gbps-class full-duplex connectivity over OM3 multimode fiber. Integrated CDR circuitry helps maintain signal integrity for reliable high-speed transmission. With a maximum reach of 70m, this commercial-grade AOC provides a plug-and-play alternative to separate transceivers and fiber patch cables, simplifying installation and cable management in high-density data centers, including switch-to-switch, switch-to-server, and storage networking applications.
Specification
| Form Factor | QSFP28 |
|---|---|
| Application | 100G Ethernet |
| Supported Protocol | IEEE 802.3bm 100GBASE-SR4 |
| Other Applications | InfiniBand FDR/EDR |
| Data Rate | 103.125Gbps |
| Optical Architecture | 4-channel parallel optics |
| Transmission | Full-duplex |
| Wavelength | 850nm |
| Fiber Type | Multimode |
| Fiber Grade | OM3 |
| Maximum Reach | 70m |
| Transmitter | VCSEL |
| Receiver | PIN |
| Modulation | NRZ |
| CDR | Yes |
| Inbuilt FEC | No |
| Power Consumption | ≤2.2W |
| Power Supply | 3.3V |
| Cable Jacket | LSZH |
| Minimum Bending Radius | 60mm |
| DDM/DOM | Supported |
| Packaging | COB |
| Connector Interface | QSFP28, 38-contact edge connector |
| Compatibility | Generic |
| Operating Temperature | 0°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| Product Class | Commercial Grade |
Features
- QSFP28 connectors on both ends
- Supports 100Gbps-class full-duplex transmission
- Four 850nm VCSEL transmit channels
- Four PIN receiver channels
- OM3 multimode fiber
- Maximum transmission distance of 70m
- Integrated CDR circuitry
- Supports 100GbE applications
- Supports InfiniBand FDR/EDR applications
- Plug-and-play direct-attach optical design
- Simplifies installation and cable management
Applications
- 100GbE data center networks
- Switch-to-switch connections
- Switch-to-server interconnects
- Storage networking
- High-performance computing
- InfiniBand FDR/EDR networks
- Short-distance data center interconnects
- High-density rack environments
FAQ
What is the maximum transmission distance of this AOC?
This 100G QSFP28 AOC supports transmission distances of up to 70m over OM3 multimode fiber.
What optical technology does the cable use?
The AOC uses four 850nm VCSEL transmit channels and four PIN receiver channels to provide parallel optical transmission.
Is this cable suitable for InfiniBand networks?
Yes. The cable is designed to support InfiniBand FDR/EDR applications as well as 100GbE Ethernet networks.
What is the advantage of using a QSFP28 AOC?
The optical transceivers and fiber cable are integrated into a single factory-terminated assembly, providing a plug-and-play connection while simplifying installation and reducing the complexity of separate transceiver and patch-cable configurations.
Where is this 100G AOC typically used?
It is suitable for data center switch-to-switch, switch-to-server, storage networking, and other short-distance 100G connections requiring high-density optical connectivity.
Quality Qulifications and Compliance
To get the detailed certification, please go to the Compliance.
Please Note: Our products comply with all internationally recognized and industry-standard specifications. For customized or special requirement products, we carry out testing and standards in accordance with the conformity criteria specified in the contract.
